Summary

Example details from the CPU rack in NORD-10 snr 619. The markings for the card type can be spotted below the connectors, M0 ... M7 is the memory slots, MPMD probably Multiport Memory Data. Multicolored cables going up is to the front panel, cables going down is to the I/O rack and white ones power.
